Flap barrier gate is a classic entrance access equipment, which provide uni-directional and bi-directional traffic with fast opening and closing. It is also called us retractable glass optical wing turnstile. When closed, the wedge-shaped glass wings meet near the top forming a barrier. When opened, the advanced design allows the glass to fully retract into the cabinet, creating an open, inviting look. With industry leading mechanical structure and advanced control system and DC motor control technology, the turnstile can work quickly & stably and validate accurately.


Features
  • One direction or bi-direction control is optional.
  • Permissions validation and anti-tailgating.
  • Channels automatically open when power off, and automatically close when power on.
  • LED indicates the entrance/exit and passing status.
  • Fire alarm passing. When the fire alarm is triggered, the barrier will be open automatically for emergency evacuation.
Applications
  • Office building
  • Subway station
  • Amusement park
  • Swimming pool
  • Schools

products
Module No INT-Y601
Size 1200INTx280x980mm
Material 304 stainless steel, acrylic
Access width 550 mm
Input voltage 100V ~ 240V
Drive motor DC 24V motor
Passing speed 40 people / minute
Applicable temperature -20~700 C
Life time 5 million times
The material thickness 1.2mm/1.5mm
Access direction Single / Bi-directional
products
Module No INT-Y602
Size 1200INTx280x980mm
Material 304 stainless steel, acrylic
Access width 550 mm
Input voltage 100V ~ 240V
Drive motor DC 24V motor
Passing speed 40 people / minute
Applicable temperature -20~700 C
Life time 5 million times
The material thickness 1.2mm/1.5mm
Access direction Single / Bi-directional
products
Module No INT-Y603
Size 1400INTx280x980mm
Material 304 stainless steel, acrylic
Access width 550 mm
Input voltage 100V ~ 240V
Drive motor DC 24V motor / DC 24V brushless motor
Passing speed 40 people / minute
Applicable temperature -20~700 C
Life time 9 million times
The material thickness 1.5mm
Access direction Single / Bi-directional
products
Module No INT-Y604
Size 1400INTx280x980mm
Material 304 stainless steel, acrylic
Access width 550 mm
Input voltage 100V ~ 240V
Drive motor DC 24V motor / DC 24V brushless motor
Passing speed 40 people / minute
Applicable temperature -20~700 C
Life time 9 million times
The material thickness 1.5mm
Access direction Single / Bi-directional
products
Module No INT-Y605
Size 1400INTx310x980mm
Material 304 stainless steel, acrylic, PU
Access width 900 mm
Input voltage 100V ~ 240V
Drive motor DC 24V brushless motor
Passing speed 40 people / minute
Applicable temperature -20~700 C
Life time 9 million times
The material thickness 1.5mm
Access direction Single / Bi-directional
products
Module No INT-Y606
Size 1400INTx310x980mm
Material 304 stainless steel, acrylic, PU
Access width 900 mm
Input voltage 100V ~ 240V
Drive motor DC 24V brushless motor
Passing speed 40 people / minute
Applicable temperature -20~700 C
Life time 9 million times
The material thickness 1.5mm
Access direction Single / Bi-directional
products
Module No INT-Y609
Size 1400INTx280x1000mm
Material 304 stainless steel, acrylic
Access width 550 mm
Input voltage 100V ~ 240V
Drive motor DC 24V motor / DC 24V brushless motor
Passing speed 40 people / minute
Applicable temperature -20~700 C
Life time 9 million times
The material thickness 1.5mm
Access direction Single / Bi-directional
